LASER eLINE horizontal

LASER eLINE horizontal

• Retrofitted installation without
  any major conversion work to do
• Invisible weld seams


Overview of Models

The electric radiator LASER eLINE horizontal is available with different dimensions.

  • 3 Columns

     Height  Height: 600
     Length  Length: 450 550 650
     depth  Deth: 101
     LASER eLINE horizontal - Nominal Output  Nominal Output:* 500 W 750 W 1000 W
     Height  Height: 600
     Lenght  Length: 750 900 1150
     Depth  Depth: 101
     LASER eLINE horizontal - Nominal Output  Nominal Output:* 1250 W 1500 W 2000 W

    Data in mm
    * at 60°C

The VOGEL&NOOT electric heating meets the requirements for the environmentally sound design of individual room heating units. This electric radiator is also ÖVE-tested.

Technical Information

The electric radiators of the LASER eLINE horizontal are elegant design and bathroom radiators with integrated electric heating.

Design: Design tubular radiators as 3 column models with water-glycol mixture.

Electric connection: Wired ready for connection (insulated cable endings) for 230 V grid connections through flush sockets, protection class II, IP 44, cable length 1,2 m.

LASER eLINE horizontal - electrical connection

Blue: Neutral conductor
Brown (or other colour): Conductor
Black: Pilot cable

Caution: The black cable marked PILOT must not be connected to the EARTH and must be insulated.

Basic serial package:
• Wall fixing set with screws and dowels
• Installation instructions
• Heating rod
• Programmable radio room thermostat
• White receiver

The towel warmer is available as an option.

Important: This radiator must be connected by a qualified electrician!

Dimensions 3 Columns

LASER eLINE horizontal - dimensions

Height 600
Length 450 550 650 750 900 1150
Depth 101
x dimension 400 500 600 700 850 1100

Data in mm

The VOGEL&NOOT electric heating meets the requirements for the environmentally sound design of individual room heating units. This electric radiator is also ÖVE-tested.

Accessories

TOWEL WARMER




LASER eLINE horizontal - towel warmer

Programmable RADIO ROOM THERMOSTAT

The basic serial features of LASER eLINE horizontal electric radiators include this radio room thermostat.

radio room thermostat

CE Marking and Declaration of Performance (DoP)

The European Union Construction Products Regulation requires that building products, including the radiators and the convectors without an integrated heat source, must be CE-marked in accordance with relevant harmonized product standards EN 442 and the Declaration of Performance (DoP). The CE marking means that each product meets the manufacturing process requirements of the product according to the provisions of manufacture, testing and delivery. The regulation came into force on July 1st, 2013.

Rettig ICC products are CE-marked and the Declaration of Performance of Rettig ICC and its reference documents, Annexes D and Annexes M describing the detailed performance of the products, are available according to the Construction Products Regulation.  See the current DoP of RICC attached and the linked document files.
