FLINT
The new interpretation of classical forms, converted with modern materials.
Architecture and design become the
crucible of time and space.
Overview of models
These high quality design radiators are made in Austria. The design radiators manufactured by VOGEL&NOOT meet numerous internationally recognised quality standards and the manufacturing processes at all of the production sites have been ISO certified.
 Length |
718 | 918 | |||
|---|---|---|---|---|---|
 Height |
1509 | 1771 | |||
 Depth |
79-91 | ||||
Zoom
Zoom
Zoom
Zoom
Technical information
Get an overview of the most important technical data. For further information, please download the featured pdf files.
-
Connection examples
Connections: 2 x external thread G ¾ (valve connection set) 1 x internal thread G ¼ (for vent plug)
Test overpressure: 13 bar
Maximum positive operating pressure: 10 bar
Maximum operating temperature: 110 °C
Flow
Return
Vent plug
Drain
Basic standard accessories (included):
• decor bands (2 or 4 sections)
• a pivotable vent plug, G 1/4, nickel-plated brass, self-sealing
• a valve connection set with angled two-pipe design
• covering rosette in matching radiator colour
• wall fastening set matching the radiator colour
• fitting aid
• instruction sheet -
Dimensions [mm]
Downloads
Here you can download all relevant data in different file formats.
- Technical information FLINT [pdf; 0.07 MB]
- Brochure FLINT [pdf; 0.12 MB]
- Technical information New Design Collection [pdf; 0.31 MB]
- Brochure New Design Collection [pdf; 0.52 MB]
- Text for invitation of tenders [pdf; 0.03 MB]
- Mounting instructions [pdf; 3.25 MB]
- Colour palette [pdf; 0.05 MB]
Colours
The FLINT design radiator is available in 72 different colours.
- 21 Sanitary colours
-
42 Standard colours
- Beige
- Golden
- Pearly White
- Ivory Light
- Traffic Yellow
- Pastel Yellow
- Blazing Red
- Ruby
- Claret
- Reddish Black
- Beige Red
- Raspberry
- Mauve
- Ultramarine
- Sapphire
- Signal Blue
- Steel Blue
- Dove Blue
- Distant Blue
- Pastel Blue
- Moss Green
- White Green
- Mint
- Silver Grey
- Slate Grey
- Anthracite
- Graphite Grey
- Stone Grey
- Light Grey
- Dust Grey
- Window Grey
- Tele Grey
- Chocolate
- Cream White
- Grey White
- White
- Traffic White
- Deep Black
- Traffic Black
- Cocoa
- Terracotta
- Cappuccino
color name color code
- 9 Metallic colours
Accessories
Basic standard accessories (included):
• decor bands (2 or 4 sections)
• a pivotable vent plug, G 1/4, nickel-plated brass, self-sealing
• a valve connection set with angled two-pipe design
• covering rosette in matching radiator colour
• wall fastening set matching the radiator colour
• fitting aid
• instruction sheet
Get an overview of our wide range of accessories for our design radiators.
